| WHEEL SIZE | BOLT HOLES | P.C.D | Center Bore Diameter | Disk Thickness | OFF SET | Rec.Tyre | ||
| HOLES NO. | HOLE DIA | HOLE TYPE | (mm) | （mm） | （mm） | (mm) | ||
| 10 | ||||||||
| 17.5x6.00 | 5 | 32.5 | SR22 | 208 | 150 | 12 | 135 | 205/65R 17.5 |
| 10 | ||||||||
| 17.5x6.00 | 5 | 29/32.5 | SR22 | 203.2 | 146 | 12 | 130 | 205/75R17.5 |
| 10 | ||||||||
| 17.5x6.00 | 6 | 20.5 | 1×45° | 190 | 140 | 12 | 130 | 215/75R17.5 |
| 10 | ||||||||
| 17.5x6.00 | 6 | 32.5 | SR22 | 222.25 | 164 | 12 | 130 | 225/70R17.5 |
| 10 | ||||||||
| 17.5x6.00 | 6 | 21.5 | 1x45/SR16 | 205 | 161 | 12 | 125 | 8.5R17.5 |
| 10 | ||||||||
| 17.5x6.00 | 8 | 25.4/26/27/24.5 | 1x45/SR18 | 275 | 221 | 12 | 134 | 9R17.5 |
| 10 | ||||||||
| 17.5x6.00 | 6 | 21.5 | 1x45 | 245 | 202 | 12 | 130/135 | 235/75R17.5 |
| 10 | ||||||||
| 17.5x6.00 | 10 | 26/27 | SR18 | 225 | 176 | 12 | 135 | 225/75R17.5 |
